Speaker Selectors

Speaker Selectors

Speaker Selectors

  • Small profile speaker selector.
  • Independent on/off switches.
  • Manual protection slide switch on bottom of switcher.
  • Custom button labels can be attached to identify each zone.
  • Stereo speaker push-type connectors on rear accept up to 12 gauge wire.
  • Boating and RV compatible.
Speaker Selectors





Frequency Response
Power Handling
Ground Paths
Input Connections
Output Connections
Dimensions with Feet (WxHxD)
Shipping Weight
SS4

SS4



Frequency Response
20Hz - 20kHz ±1dB
Power Handling
40 watt/channel with protection engaged; 120 watt/channel without protection engaged
Ground Paths
Separate left and right ground paths for compatibility with all amps, even bridged
Input Connections
One stereo source input (speaker level)
Output Connections
4 stereo speaker push-type connectors on rear accept up to 12 gauge wire
Dimensions with Feet (WxHxD)
8 1/2" x 2" x 7" (286mm x 51mm x 178mm)
Shipping Weight
3 lbs (1.4kg)
SS6

SS6



Frequency Response
20Hz - 20kHz ±1dB
Power Handling
40 watt/channel with protection engaged; 120 watt/channel without protection engaged
Ground Paths
Separate left and right ground paths for compatibility with all amps, even bridged
Input Connections
One stereo source input (speaker level)
Output Connections
6 stereo speaker push-type connectors on rear accept up to 12 gauge wire
Dimensions with Feet (WxHxD)
11 1/4" x 2" x 7" (286mm x 51mm x 178mm)
Shipping Weight
3 lbs (1.4kg)
Speaker Selectors - Line Art
