Visual Performance

Large Rectangle

Large Rectangle

  • 3-way speaker system for audiophile quality sound.
  • Coaxial midrange and tweeter provide superior clarity and detail.
  • 8" woofer delivers exceptional bass response and authority, typical of large cabinet speakers.
  • Tweeter level switch on VP88 allows high frequencies to be adjusted to suite the install environment.
  • Independently pivoting midrange/tweeter.
  • Three performance levels to accommodate any ear or budget.
Large Rectangle





Tweeter
Midrange
Woofer
Frequency Response
Impedance
Power Handling
Sensitivity
Adjustments
Shipping Weight
VP82

VP82



Tweeter
1" (25mm) cloth dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
Midrange
4" (102mm) textured polypropylene cone with a rubber surround, pivoting
Woofer
8" (203mm) textured polypropylene cone with a rubber surround
Frequency Response
38Hz - 20kHz ±3dB
Impedance
8 ohms nominal; 6 ohms minimum
Power Handling
5 watts minimum; 125 watts maximum
Sensitivity
90dB SPL (2.83V/1 meter)
Adjustments
Shipping Weight
20 lbs (9kg) pair
VP86

VP86



Tweeter
1" (25mm) powder-coated aluminum dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
Midrange
4" (102mm) Kevlar/Nomex laminated cone with a rubber surround, pivoting
Woofer
8" (203mm) Kevlar/Nomex laminated cone with a rubber surround
Frequency Response
34Hz - 20kHz ±3dB
Impedance
8 ohms nominal; 6 ohms minimum
Power Handling
5 watts minimum; 150 watts maximum
Sensitivity
91dB SPL (2.83V/1 meter)
Adjustments
Shipping Weight
20 lbs (9kg) pair
VP88

VP88



Tweeter
1" (25mm) ceramic dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
Midrange
4" (102mm) Carbon fiber/Rohacell laminated cone with a rubber surround, pivoting
Woofer
8" (203mm) Carbon fiber/Rohacell laminated cone with a rubber surround
Frequency Response
30Hz - 20kHz ±3dB
Impedance
6 ohms nominal; 4 ohms minimum
Power Handling
5 watts minimum; 175 watts maximum
Sensitivity
91dB SPL (2.83V/1 meter)
Adjustments
Tweeter Level Switch -3dB Flat +3dB
Shipping Weight
22 lbs (10kg) pair

Shared Specifications

10" (254mm) x 16" (406mm)
8 1/2" (216mm) x 14 1/2" (368mm)
3 7/8" (98mm)
Perforated Steel
Large Rectangle - Line Art
